UD Electrodynamic Testing Machines

.

VERSATILE DESIGN, USER-FRIENDLY INTERFACE

..........

UD Series	Units	UD01	UD02	UD04	UD08	UD012	UD020	UD025	UD030	UD040	UD060
Maximum dynamic force	[kN][lbf]	0.7 – 157.3	2.4 – 539.5	4.0 – 899.2	8.0 – 1798.5	12.0 – 2697.7	20.0 – 4496.2	25.0 – 5620.2	30.0 – 6744.3	40.0 – 8992.3	60.0 – 13488.5
Maximum static force	[kN][lbf]	0.5 – 112.4	1.5 – 3372.1	3.0 – 674.4	6.0 – 1349.9	9.0 – 2023.3	15.0 – 3372.1	18.0 – 4046.5	21.0 – 4720.9	30.0 – 6744.2	45.0 – 10116.4
Maximum test speed	[m/s] [in/s]	2.0 – 78.7	2.0 – 78.7	2.0 – 78.7	2.0 – 78.7	2.0 – 78.7	2.0 – 78.7	2.0 – 78.7	2.0 – 78.7	2.0 – 78.7	2.0 – 78.7
Maximum test frequency	[Hz]	>250*	>250*	>250*	>250*	>250*	>250*	>250*	>100*	>100*	>100*
Standard stroke	[mm] [in]	80 – 3.1	100 – 3.9	70 – 2.7	70 – 2.7	70 – 2.7	80 – 2.7	70 – 2.7	60 – 2.3	80 – 2.7	80 – 2.7
Cooling		Air	Air	Air	Air	Air	Water closed circuit	Water closed circuit	Water closed circuit	Water closed circuit	Water closed circuit
Operating temperature	[C°]	5-30	5-30	5-30	5-30	5-30	5-30	5-30	5-30	5-30	5-30
Installation requirements		3PH 400V	3PH 400V	3PH 400V	3PH 400V	3PH 400V	3PH 400V	3PH 400V	3PH 400V	3PH 400V	3PH 400V
